Mounts

CAS offers tank mounts in capacities ranging from light to heavy capacity. Available in mild steel, stainless steel, and hybrid configurations. Utilize environmentally protected, welded sealed, and hermetically sealed load cells to empower you with the ability to configure the right product at the right price.

Make any tank or vessel into a scale - Ideal for process control & traceability needs.

  • Isolated Tension Mounts
  • Single Ended Beam Mounts
  • Double Ended Beam Mounts
  • Pancake Mounts
  • Canister Mounts
3 Mount or 4 Mount Kits Available - Kits include tank mounts, load cells, stainless steel NEMA 4X junction box, and load cell cable.
Isolated Tension Mount

Isolated Tension Mounts – ITM’s combine multidirectional movement with self-checking capabilities and added load cell protection with Teflon insulator and load cell shunt/bonding strap.

CAS ITM’s assemblies are available in cold steel, zinc plated, and stainless steel mount assemblies. Choose the load cell from a wide array of materials including environmentally protected aluminum, environmentally protected stainless steel, and stainless steel with a complete hermetic seal in capacities from 50 lbs. – 20,000 lbs.

Isolated tension mount assembly with alloy steel load cell in capacities ranging from 50 lbs to 20,000 lbs.

Isolated tension mount assembly available with a stainless steel potted S beam load cell with either a galvanized steel or stainless steel mount. Capacities range from 220 lbs to 11,000 lbs.
Choose from a galvanized steel mount and stainless steel mount, multi-direction movement with self checking capabilities and load cell isolation. S-beam load cell with complete hermetic seal. Capacities range from 225 lbs to 1,125 lbs.
Choose from a galvanized steel mount and stainless steel mount, multi-direction movement with self checking capabilities and load cell isolation. S-beam load cell with complete hermetic seal. Capacities range from 2,250 lbs to 11,240 lbs.
Single Ended Beam Tank Mounts
Single ended beam tank mounts – light to medium capacity assemblies available in capacities from 250 lbs. to 20,000 lbs. Mild steel, galvanized, stainless steel, and hybrid tank mounts with various types of loading and checking mechanicisms are available with mild steel (environmentally protected – IP65/IP67), stainless steel (hermetic seal welded cap – IP67), and stainless steel (with complete hermetic seal- IP68/IP69K )load cells available.
Stainless steel single ended shear beam mount with neoprene isolation pad. Accommodates vibration and thermal expansion. Mild steel or stainless steel load cells rated IP65/IP67 with capacities from 50 lbs. to 5,000 lbs.
CAS-5205 – Low profile, stainless steel single ended shear beam mount with self aligning rubber element with flange. Stainless steel load cell with complete hermetic seal, rated IP68/IP69K. Available in capacities from 1,125 lbs to 4,500 lbs
CAS-5213 – Galvanized steel and stainless steel single ended shear beam mount with multi-direction sliding system. Stainless steel load cell with complete hermetic seal, rated IP68/IP69K. Available in capacities from 500 lbs. to 22,500 lbs.
Mild or stainless steel single ended shear beam mount. Ideal for multi-directional movement w/self-checking. Alloy or stainless steel IP67 rated load cells feature environmentally protected or hermetic seal welded cap designs. 250 lbs to 10,000 lbs capacities.
CAS-RTM – Stainless steel single ended shear beam mount with a stainless steel hermetic seal welded cap load cell, rated IP67, in capacities from 500 lbs. to 10,000 lbs. Expansion and contraction due to thermal changes and side loading is handled by rocker pin mounting.
Mild steel and stainless steel single ended shear beam mount assembly with articulating mounting plate. Mild steel or stainless steel load cells with hermetic seal welded cap, IP67 rated. Ranging in capacities from 250 lbs. to 20,000 lbs.
Double Ended Beam Tank Mounts
Double ended beam tank mounts – medium to heavy capacity assemblies available in capacities from 1,000 lbs. to 250,000 lbs. Mild steel, stainless steel, and hybrid tank mounts configurable for applications that require varying degrees of expansion, contraction, vibration, side loads, and bending movements. Available load cells include mild steel and stainless steel environmentally protected load cells rated IP65 to hermetic seal welded cap load cells rated IP67.
These mild steel and stainless steel double ended shear beam mounts are ideal for applications that see a lot of agitation, vibration, or expansion and contraction. Mild steel or stainless steel environmentally protected to hermetic seal welded cap IP67 rated load cells are available in capacities from 5,000 lbs. to 250,000 lbs.
Very popular, self-checking, easy to install, center pivot loading mild steel or stainless steel double ended shear beam mount. Mild steel or stainless steel environmentally protected to hermetic seal welded cap IP67 rated load cells are available in capacities from 1,000 lbs. to 125,000 lbs.

Alloy Steel Load Cell w/Mild Steel Mount Capacities ranging from 10K lbs to 75K lbs

Canister Assembly Tank Mounts
Canister assembly tank mounts – medium to heavy capacity assemblies available in capacities from 1,000 lbs. to 300,000 lbs. Alloy steel, stainless steel, and hybrid mounts (stainless steel load cell with steel mount assembly), IP 67 rated, complete with integral mounting plates and various profile heights.
Low profile stainless steel canister assembly with integral mounting plates. Designed for use with tanks, bins, hoppers, & silos. Available in 10K to 50K capacities.
Tank weighing assembly designed for tanks, bins, reactors, and large capacity storage silos. Available in multiple configurations. Capacities range from 50K to 300K.
The CAS-SP9M tank mount assembly uses a hermetically sealed canister load cell with two attached mounting plates. The lower plate is rigidly mounted to the load cell. The top plate allows horizontal expansion but does not separate from the load cell. Capacities range from 50K to 300K.
